SolarEast BLN R290: compare the exact variant
The catalogue groups BLN-006TC1, BLN-012TC1, BLN-012TC3 and BLN-018TC3 on this family page. The two 12kW references have different phase designations in the table: specify the full model code, not just the nominal kW size.
Read capacity and efficiency in context
The existing table contains capacity and COP ranges at the listed water-temperature conditions. A range is not a fixed rated output at every outdoor temperature. Before comparing another heat pump, match the air/water test conditions and identify whether a value is a rated point, modulation range or seasonal figure. The maximum water temperature alone does not establish radiator compatibility.
From product data to a project choice
Send the building heat-loss information, required water temperatures, existing emitters and available electrical supply. Include domestic hot-water demand, zones, proposed outdoor location and hydraulic arrangement. Installation and final selection require the applicable model documentation and project review.
Use the existing engineering tools
Start with the heat-pump selector, review existing emitters with the radiator checker, and prepare the circuit information with the hydraulic precheck. These tools support the enquiry; they do not replace final engineering design.
Manufacturer sources and the technical documents below support further review. Ask us to confirm the exact supplied unit, accessories and availability in your quotation.
Technical table
| Model | Nominal size | Phase | Heating capacity at 35°C water | Heating capacity at 55°C water | Cooling capacity | COP at 35°C water | COP at 55°C water | Refrigerant | Max outlet water temperature | Water connection | Dimensions | Weight |
|---|---|---|---|---|---|---|---|---|---|---|---|---|
| BLN-006TC1 | 6kW | Single phase | 2.92 ~ 9.10 kW | 2.99 ~ 8.16 kW | 1.38 ~ 5.70 kW | 4.31 ~ 5.66 | 2.79 ~ 3.46 | R290 / 0.55 / 3 | 75°C | G1 | 1187*418*805 mm | 110 kg |
| BLN-012TC1 | 12kW | Single phase | 4.30 ~ 15.20 kW | 4.25 ~ 14.55 kW | 3.65 ~ 11.04 kW | 4.07 ~ 5.57 | 2.83 ~ 3.45 | R290 / 1.05 / 3 | 75°C | G1 | 1287*448*904 mm | 134 kg |
| BLN-012TC3 | 12kW | Three phase | 4.30 ~ 15.20 kW | 4.25 ~ 14.55 kW | 3.65 ~ 11.04 kW | 4.07 ~ 5.57 | 2.83 ~ 3.45 | R290 / 1.05 / 3 | 75°C | G1 | 1287*448*904 mm | 134 kg |
| BLN-018TC3 | 18kW | Three phase | 7.24 ~ 21.90 kW | 6.36 ~ 19.45 kW | 4.55 ~ 17.20 kW | 3.82 ~ 5.59 | 2.84 ~ 3.57 | R290 / 1.4 / 3 | 75°C | G1 ~ 1 / 4 | 1187*488*1456 mm | 195 kg |
Technical documents (6)
For an accurate quote, send us
- Where the product will be used
- Quantity or dimensions where available
- Photos, drawings or material list if available
- Whether you need store collection or delivery
- Building size and type
- Existing heating system (radiators, underfloor, fan coil)
- Single or three-phase supply
- Domestic hot water requirement
